Cymex 5 sizing software makes the entire drivetrain quicker and more reliably

Highlights from Wittenstein at Hannover include the following: With cymex 5 sizing software, the entire drivetrain (application + transformation + gearhead + motor) can now be sized and designed quicker and more reliably. Its calculations are considerably simplified by predefined standard applications. Optimally sized and more efficient motors are achieved by abstracting all important influencing factors. The ultra-compact and dynamic IDS3010 is a contactless measuring sensor for the engineering industry. With a data acquisition bandwidth of 10 MHz, the IDS3010 simultaneously tracks up to three axes at velocities of 2 m/s. The sensor provides a position resolution of one picometer and reaches working distances of up to five meters. The alpha Value Line is universally suitable: it represents the most economical solution whatever the requirements for driving any axis in virtually any industry. Each input or output interface for the alpha Value Line was developed as a compatible add-on for Wittenstein alpha's existing high-end portfolio. With the servo actuator TPM+, precision planetary gearheads and synchronous servomotors are integrated without a clutch for a unit that is flexible in its application. In combination with short overall lengths, high power-density, and smooth running: this marks a whole new level of performance - along with practical, graduated performance settings that ensure greater operating efficiency in all your production applications. Experience extraordinary dynamics thanks to modern motor technology with high power density, a low moment of inertia and optimal torsional rigidity. Benefit from a reduced installation length: The coupling-free connection between motor and gearbox and the space-saving attachment of motor instruments make the TPM+ DYNAMIC 50 percent more compact than conventional gearbox motors. Helical-toothed precision planetary gearboxes ensure low-vibration and silent operation.
